HEDRA CLIP 93008 B-B
Black-Black - 22519 9310 B-B
VIZIR TUBE B
Black - 473 01 00 B
CRI
Beam angle
CCT
General
| Location | Indoor |
| CCT | 3000K |
| Fixation | Ceiling |
| Installation | Recessed, Surface mounted |
| Cutout shape | round |
| Cutout size (mm) | 51 |
| Min. recessed depth (mm) | 40 |
| IP | IP20 |
| Weight (kg) | 0.3 |
| Adjustability | 0° to 90° swiveling, 355° rotatable |
| Information | LENS SP-8°
EXCL.LED POWER SUPPLY 350-500mA-DC |
Electrical
| Class | III |
| Dimming type | depending on power supply |
| Energy class | F |
| Certificates | CB, ENEC |
Lightsource
| Light source | LED |
| LED information | LED array 3,9-5,7W / CRI>90 (R9: 55) / 3000K / 385-519lm |
| TM-30 Values | rf: 92 / Rg: 98 |
| SDCM | SDCM2 |
| Riskgroup | RG2 (threshold 0,6m) |
| LM80 | L90B10 > 41000 |
| LED technics (light source) | 519lm // 5,7W // 90lm/W |
| LED technics (luminaire) | 397lm // 7W // 61lm/W |
Additional
| Requirements | VIZIR TUBE
LED POWER SUPPLY 350 / 500mA-DC DIM |
| Options | MOUNTING KIT FLUSH SPY |
| Accessories | VIZIR HONEYCOMB
VIZIR SOFTENING LENS |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Ceiling compatibility
Please find an overview of the suitable ceiling types for this specific product.
Ceiling Type
Mounting kit
-
-
-
-
Finish your specifications
Use the information listed below to complete your product
