Specifications | Downloads
Add to pinlist

General

Location
Indoor
Cutout shape
round
Cutout size (mm)
55
IP
IP20
Weight (kg)
0.1
Information
OUTPUT:
250mA / 12W (110V:12W) / 15-49V-DC 350mA / 17W (110V:15W) / 10-49V-DC 450mA / 20W (110V:15W) / 5-45V-DC 500mA / 20W (110V:15W) / 5-40V-DC 700mA / 20W (110V:15W) / 3-28V-DC λ > 0,9 Inrush current : 5A - 50µs @ 230V-AC Max. 50 units on circuit breaker B 16A @ 230V-AC

Electrical

Voltage
110-240V / 0|50-60Hz
Class
II
Dimming type
DALI
Technical data was measured in optimum conditions.
