iMAX II ADJUSTABLE TRIMLESS LP 92712

iMAX II TUBE ROUND TRIMLESS B

Black - 24213 0020 B
More info
CRI
Beam angle
CCT

General

Location
Indoor
CCT
2700K
Fixation
Ceiling
Installation
Recessed
Cutout shape
round
Cutout size (mm)
Ø KIT
Max. recessed depth (mm)
160
IP
IP20
Weight (kg)
0.3
Adjustability
0° to 30° swiveling, 355° rotatable
Information
LENS FL-20° EXCL.LED POWER SUPPLY 350-500mA-DC

Electrical

Class
III
Dimming type
depending on type of external power supply
Energy class
F

Lightsource

Light source
LED
LED information
LED array 5,8-8,6W / CRI>90 (R9: 60) / 2700K / 702-974lm
TM-30 Values
Rf: 89 / Rg: 100
SDCM
SDCM1
Riskgroup
RG1
LM80
L90B10 > 50000
LED technics (light source)
974lm // 8,6W // 113lm/W
LED technics (luminaire)
794lm // 10W // 80lm/W

Additional

Requirements
LED POWER SUPPLY 350 / 500mA-DC DIM MOUNTING KIT R102 TRIMLESS O.F.A. iMAX II TUBE TRIMLESS
Accessories
iMAX II ACCESSOIRES
Technical data was measured in optimum conditions.

Downloads

Following downloads are available:

Ceiling compatibility

Please find an overview of the suitable ceiling types for this specific product.
