CARREE TRIMLESS OK SOFT 93045 B
Black - 11049 9030 B
CRI
Beam angle
CCT
General
| Location | Indoor |
| CCT | 3000K-1800K |
| Fixation | Ceiling |
| Installation | Recessed |
| Cutout shape | rectangle |
| Cutout size (mm) | KIT |
| Min. recessed depth (mm) | 85 |
| IP | IP20 |
| Weight (kg) | 0.3 |
| Adjustability | 0° to 25° swiveling |
| Information | REFLECTOR WFL-45°
EXCL.DIMMABLE LED POWER SUPPLY 500mA-DC |
Electrical
| Class | III |
| Dimming type | depending on power supply |
| Energy class | F |
| Certificates | CB, ENEC |
Lightsource
| Light source | LED |
| LED information | LED array 10,2W / CRI>90 (R9: 50) / 3000K-1800K / 1038lm |
| SDCM | SDCM2 |
| Riskgroup | RG1 |
| LM80 | L90B10 > 50000 |
| LED technics (light source) | 1038lm // 10,2W // 109lm/W |
| LED technics (luminaire) | 829lm // 12W // 71lm/W |
Additional
| Requirements | LED POWER SUPPLY 500mA-DC DIM (Remote)
MOUNTING KIT 75 TRIMLESS
MOUNTING KIT 75 TRIMLESS O.F.A. |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Ceiling compatibility
Please find an overview of the suitable ceiling types for this specific product.
Ceiling Type
Mounting kit
Finish your specifications
Use the information listed below to complete your product
requirement
LED power supplies
Mounting kits
| Product name | Cutout shape | Cutout size | Thickness of mounting surface | ||
|---|---|---|---|---|---|
 | MOUNTING KIT 75 TRIMLESS | round | 121 | 9 or 12 | Add to pinlist |
 | MOUNTING KIT 75 TRIMLESS O.F.A. | round | 182 | - | Add to pinlist |
