Find your product
TECHNICAL
ACCESSOIRE/OPTION
Technical products
Overview
required
Emergency units
Current supply
Special components
LED retrofit lamps
LED flex and parts
LED power supplies
Power box
Miscellaneous control equipment
Plasterkits
Concrete packs
Mounting kits
Mounting kits stretched ceiling
Coversets
Ground mounting boxes
Waterproof connection parts
| Product name | Information | ||
|---|---|---|---|
 | MICRO VISOR B | - | Add to pinlist |
 | CONCRETE PACK MGIT 2 | - | Add to pinlist |
 | MINIGRID IN 2 MOUNTING KIT LARGE | - | Add to pinlist |
 | CONCRETE PACK MGIT 1 | - | Add to pinlist |
 | MINIGRID IN 2 MOUNTING KIT HP | - | Add to pinlist |
 | MINIGRID IN 1 MOUNTING KIT HP | - | Add to pinlist |
 | MINIGRID IN 1 MOUNTING KIT LARGE | - | Add to pinlist |
 | MINIGRID IN 1 MOUNTING KIT | - | Add to pinlist |
 | CBOX | INCL.2 x PG13,5 / 1 x PG11 | Add to pinlist |
 | IP68 CONNECTION KIT | CABLE Ø 7,5-10 mm MAX.3 x 4mm² 4A 250V-AC | Add to pinlist |
 | IP68 CONNECTOR 3P | CABLE Ø 7,5-12 mm MAX.3 x 1,5mm² 4A 250V-AC | Add to pinlist |
| | CBOX 350 mA / 10W | INCL.2 x PG13,5 / 2 x PG11 INCL.LED POWER SUPPLY 350mA-DC / 10W CURRENT CONTROLLED | Add to pinlist |
 | LED POWER CONVERTER 48V-DC to 700 mA-DC / 25W DIM5 | INPUT : 48V-DC OUTPUT : 700mA-DC / 25W max. OUTPUT : 5,5 - 42V-DC | Add to pinlist |
 | WIRELESS DALI CONTROLLER PS 16 | Max.16 DALI driver addresses With integrated bus power supply Inrush current: 20 A Supports DALI D4i, DALI DT6, and DALI DT8 DALI output voltage: 12 – 15 VDC | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 150W DIM8 | WITH CABLE CLAMP OUTPUT: 24V-DC / 150W Dimming method: PWM (3kHz) λ > 0,9 Inrush current : < 60A - 250µs @ 230V-AC Max. 14 units on circuit breaker B 16A @ 230V-AC | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 75W DIM8 | WITH CABLE CLAMP OUTPUT: 24V-DC / 75W Dimming method: PWM (3kHz) λ > 0,9 Inrush current : < 50A - 250µs @ 230V-AC Max. 12 units on circuit breaker B 16A @ 230V-AC | Add to pinlist |
 | EMERGENCY UNIT 7W / 1h + LED INDICATOR HOLDER B | OUTPUT: 9-58 V-DC / 25-200mA Ni-MH BATTERY 7,2V - 2Ah 1h Emergency Operation Charging time: 24h Green signal LED + holder included | Add to pinlist |
| | LED POWER CONVERTER 48V-DC to 500 mA-DC / 22W DIM5 | INPUT : 48V-DC OUTPUT : 500mA-DC / 22W max. OUTPUT : 5,5 - 42V-DC | Add to pinlist |
 | WIRELESS DALI CONTROLLER BP 16 | Max.16 DALI driver addresses Bus powered Input voltage: 9,5-22,5 V Supports DALI D4i, DALI DT6, and DALI DT8 | Add to pinlist |
 | LEDFLEX IN RGB/TW | MAX.L / FLEX : 5m 96 x SMD LED/m DIVIDABLE PER 62,5mm 24V-DC RGB: 11,52W/m - TW:3,4W/m | Add to pinlist |
 | LEDFLEX IN CONNECTION SET | SET OF 10 PCS 2 x 0.35mm² / 150 mm | Add to pinlist |
 | LEDFLEX OUT RGB | MAX.L / FLEX : 5m 120 SMD LED/m DIVIDABLE PER 25mm 24V-DC | Add to pinlist |
 | LEDFLEX IN CONNECTION CLIP SET | SET OF 10 PCS | Add to pinlist |
 | LEDFLEX IN SUPPLY CABLE SET | SET OF 10 PCS 2 x 0.35mm² / 150 mm | Add to pinlist |
 | KAP STRIPER B | - | Add to pinlist |
 | TIGA V-PLATE W | - | Add to pinlist |
 | TIGA V-PLATE B | - | Add to pinlist |
 | PIN 3 | - | Add to pinlist |
 | PIN 1 | - | Add to pinlist |
 | PIN 4 | - | Add to pinlist |
 | CABLE BASE R ANO | - | Add to pinlist |
| | CABLE BASE R B | - | Add to pinlist |
 | IP68 Y-CONNECTOR 5P | CABLE Ø 5-17 mm MAX.5 x 1,5mm² 32A 450V-AC | Add to pinlist |
 | LED POWER SUPPLY MULTI POWER | OUTPUT:<BR> 350mA / 15W / 15-44V-DC 500mA / 24W / 10-44V-DC 650mA / 28,5W / 10-44V-DC 700mA / 30,5W / 10-44V-DC 1050mA / 40W / 10-38V-DC λ > 0,9 Inrush current : 5A - 50µs @ 230V-AC Max. 50 units on circuit breaker B 16A @ 230V-AC | Add to pinlist |
 | LED POWER SUPPLY MULTI POWER DIM5 | OUTPUT:<BR> 350mA / 18W / 10-54V-DC 500mA / 27W / 10-54V-DC 650mA / 35W / 10-54V-DC 700mA / 38W / 10-54V-DC 1050mA / 38W / 10-36V-DC λ > 0,9 Inrush current : 5A - 50µs @ 230V-AC Max. 50 units on circuit breaker B 16A @ 230V-AC | Add to pinlist |
 | PLASTERKIT 170 | - | Add to pinlist |
 | LED POWER SUPPLY MULTI POWER DIM1 | OUTPUT:<BR> 350mA / 18W / 10-54V-DC 500mA / 27W / 10-54V-DC 650mA / 35W / 10-54V-DC 700mA / 36W / 10-51V-DC 1050mA / 36W / 10-35V-DC λ > 0,9 Inrush current : 5A - 50µs @ 230V-AC Max. 50 units on circuit breaker B 16A @ 230V-AC | Add to pinlist |
 | LED POWER SUPPLY MULTI-POWER COMPACT WDL | OUTPUT:<BR> 350mA / 18,5W / 10-54V-DC 450mA / 24W / 10-54V-DC 500mA / 27W / 10-54V-DC 650mA / 35W / 10-54V-DC 700mA / 36W / 10-51V-DC 900mA / 38W / 10-42V-DC 1050mA / 38W / 10-36V-DC λ > 0,9 Inrush current : 5A - 50µs @ 230V-AC Max. 50 units on circuit breaker B 16A @ 230V-AC | Add to pinlist |
 | PLASTERKIT 186 | - | Add to pinlist |
 | PLASTERKIT 161 | - | Add to pinlist |
 | CABLE BASE S B | - | Add to pinlist |
| | CABLE BASE S W | - | Add to pinlist |
 | COVERSET R 100 B | - | Add to pinlist |
 | COVERSET R 100 W | - | Add to pinlist |
 | SUPERLOOP POWERBOX H9 1200mA DIM5 W | <p>Suited for 2 or 3 cable suspension </p> INCL.DIMMABLE LED POWER SUPPLY 1200mA / 52W λ > 0,9 Inrush current : 10A - 200µs @ 230V-AC Max. 30 units on circuit breaker B 16A | Add to pinlist |
 | PANEL 120 LIGHT GREY | PET-FELT (100% Polyester - 60% recycled origin) | Add to pinlist |
 | PANEL 120 DARK GREY | PET-FELT (100% Polyester - 60% recycled origin) | Add to pinlist |
| | PANEL 70 DARK GREY | PET-FELT (100% Polyester - 60% recycled origin) | Add to pinlist |
| | PANEL 90 LIGHT GREY | PET-FELT (100% Polyester - 60% recycled origin) | Add to pinlist |
| | PANEL 90 DARK GREY | PET-FELT (100% Polyester - 60% recycled origin) | Add to pinlist |
 | LED POWER SUPPLY 250mA-DC / 10W DIM5 | OUTPUT: 250mA / 10W / 2,5-45V-DC λ > 0,9 Inrush current : 5A - 100µs @ 230V-AC Max. 130 units on circuit breaker B 16A @ 230V-AC | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 60W IP67 DIM1 | OUTPUT: 24V-DC / 60W λ > 0,95 Inrush current : 50A - 270µs @ 230V-AC Max. 9 units on circuit breaker B 16A | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 90W IP67 DIM5 | OUTPUT: 24V-DC / 90W λ > 0,95 Inrush current : 60A - 550µs @ 230V-AC | Add to pinlist |
| | LED POWER SUPPLY 24V-DC / 60W IP67 DIM5 | OUTPUT: 24V-DC / 60W λ > 0,95 Inrush current : 50A - 270µs @ 230V-AC Max. 9 units on circuit breaker B 16A | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 120W DIM1 | OUTPUT: 24V-DC / 120W Dimming method: PWM λ > 0,95 Inrush current : 60A - 280µs @ 230V-AC Max. 8 units on circuit breaker B 16A | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 60W DIM5 | OUTPUT: 24V-DC / 60W Dimming method: current reduction λ > 0,95 Inrush current : 18A - 2,8µs @ 230V-AC Max. 54 units on circuit breaker B 16A | Add to pinlist |
 | LED POWER SUPPLY MULTI POWER 60-360mA-DC | OUTPUT: 60mA-DC / 2,5W / 2-41,5V-DC OUTPUT: 100mA-DC / 4,1W / 2-41,5V-DC OUTPUT: 180mA / 7,4W / 2-41,5V-DC OUTPUT: 240mA / 10W / 2-41,5V-DC OUTPUT: 300mA / 12,4W (10W@110V) / 2-41,5V-DC OUTPUT: 360mA / 15W (10W@110V) / 2-41,5V-DC λ > 0,8 Inrush current : 27A - 250µs @ 230V-AC Max. 27 units on circuit breaker B 16A @ 230V-AC | Add to pinlist |
| | LED POWER SUPPLY 24V-DC / 90W IP67 DIM1 | OUTPUT: 24V-DC / 90W λ > 0,95 Inrush current : 60A - 550µs @ 230V-AC | Add to pinlist |
| | LED POWER SUPPLY 24V-DC / 120W IP67 DIM1 | OUTPUT: 24V-DC / 120W λ > 0,95 Inrush current : 60A - 520µs @ 230V-AC Max. 4 units on circuit breaker B 16A | Add to pinlist |
| | LED POWER SUPPLY 24V-DC / 120W IP67 DIM5 | OUTPUT: 24V-DC / 120W λ > 0,95 Inrush current : 60A - 520µs @ 230V-AC Max. 4 units on circuit breaker B 16A | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 24W | OUTPUT: 24V-DC / 24W λ > 0,95 Inrush current : 30A - 280µs @ 230V-AC Max. 50 units on circuit breaker B 16A | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 90W DIM1 | OUTPUT: 24V-DC / 90W Dimming method: PWM λ > 0,95 Inrush current : 50A - 280µs @ 230V-AC Max. 10 units on circuit breaker B 16A | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 60W DIM1 | OUTPUT: 24V-DC / 60W Dimming method: PWM λ > 0,95 Inrush current : 40A - 280µs @ 230V-AC Max. 12 units on circuit breaker B 16A | Add to pinlist |
 | LED FILAMENT A60 E27 6W 2700K | EQUIVALENT WITH INCANDESCENT LAMP 53W LIFETIME: 20000hrs | Add to pinlist |
 | LED FILAMENT T45 E27 8W 2700K - MIST | MAINS DIMMING - TRAILING EDGE | Add to pinlist |
 | LOGIC 60 BOX R | INCL.BASE PLATE EXCL.LED POWER SUPPLY max.500kg | Add to pinlist |
 | LOGIC 90 BOX S | INCL.BASE PLATE EXCL.TRANSFO max.500kg | Add to pinlist |
 | LOGIC 90 BOX R | INCL.BASE PLATE EXCL.TRANSFO max.500kg | Add to pinlist |
 | M26H - VOICE COMMAND GOOGLE HOLDER W | HOLDER FOR GOOGLE HOME NEST MINI 2°GEN SPEAKER INCL.48V-14V CONVERTOR + DC JACK FOR CONNECTION WITH SPEAKER | Add to pinlist |
 | M26H - VOICE COMMAND GOOGLE HOLDER B | HOLDER FOR GOOGLE HOME NEST MINI 2°GEN SPEAKER INCL.48V-14V CONVERTOR + DC JACK FOR CONNECTION WITH SPEAKER | Add to pinlist |
 | M26L - VOICE COMMAND GOOGLE HOLDER W | HOLDER FOR GOOGLE HOME NEST MINI 2°GEN SPEAKER INCL.48V-14V CONVERTOR + DC JACK FOR CONNECTION WITH SPEAKER | Add to pinlist |
 | DALI VOICE CONTROL | DALI 1 CHANNEL WI-FI VOICE CONTROLLER to be used in combination with VOICE COMMAND GOOGLE HOLDER connect up to 64 DALI DEVICES DALI compatible output according to IEC 62386 standard, broadcast mode Wi-Fi connection 2.4 GHz with internet access | Add to pinlist |
 | LED POWER SUPPLY 48V-DC / 90W | OUTPUT: 48V-DC / 90W λ > 0,9 Inrush current : 60A - 550µs @ 230V-AC Max. 3 units on circuit breaker B 16A | Add to pinlist |
 | DALI MIDNIGHT CONTROL | Module for automatic power reduction / brightness reduction for night-time Up to 7 standard DALI loads, extension possible to max. 64 loads is possible with a DALI REPEATOR (300 90 137) | Add to pinlist |
 | AMBIENT LIGHT SENSOR AND 24V DIMMER (PWM) | Output signal: 24V - PWM Frequency: 800Hz (flicker free) Max. 5A | Add to pinlist |
 | M - DALI PRESENCE AND DAYLIGHT SENSOR (FULL DALI) | PRESENCE and DAYLIGHT 0,1W max. | Add to pinlist |
| | LED POWER CONVERTER 48V-DC to 700 mA-DC / 25W PRO DIM5 | INCL.THROUGH WIRING PLUG INPUT : 48V-DC OUTPUT : 700mA-DC / 25W max. OUTPUT : 5,5 - 42V-DC | Add to pinlist |
 | LED POWER SUPPLY 48V-DC / 90W DIM1 | OUTPUT: 48V-DC / 90W λ > 0,9 Inrush current : 60A - 550µs @ 230V-AC Max. 3 units on circuit breaker B 16A | Add to pinlist |
 | LED POWER SUPPLY 48V-DC / 90W DIM5 | OUTPUT: 48V-DC / 90W λ > 0,9 Inrush current : 60A - 550µs @ 230V-AC Max. 3 units on circuit breaker B 16A | Add to pinlist |
| | WIRELESS DALI CONTROLLER BP 64 | Max.64 DALI driver addresses Bus powered Input voltage: 9,5-22,5 V Supports DALI D4i, DALI DT6, and DALI DT8 | Add to pinlist |
| | LED POWER CONVERTER 48V-DC to 350 mA-DC / 15W DIM5 | INPUT : 48V-DC OUTPUT : 350mA-DC / 15W max. OUTPUT : 5,5 - 42V-DC | Add to pinlist |
| | WIRELESS DALI CONTROLLER BP 32 | Max.32 DALI driver addresses Bus powered Input voltage: 9,5-22,5 V Supports DALI D4i, DALI DT6, and DALI DT8 | Add to pinlist |
| | LEDFLEX OUT RGB 5m | MAX.L / FLEX : 5m 120 SMD LED/m DIVIDABLE PER 25mm 24V-DC INCL.10 MOUNTING BRACKETS INCL.3 END CAPS INCL.2 SUPPLY CAPS 180° INCL.1 SUPPLY CAP 90° | Add to pinlist |
 | PLASTERKIT 126 | - | Add to pinlist |
 | SLM - CURRENT SUPPLY SET 4 x 0,75mm² 1,6m DIM5 | - | Add to pinlist |
| | SLM - CURRENT SUPPLY SET 2 x 0,75mm² 1,6m MDL | - | Add to pinlist |
 | SLM - CURRENT SUPPLY SET 6 x 0,75mm² 1,6m BLACK DIM5 UP | - | Add to pinlist |
 | MOUNTING KIT 75 TRIMLESS | - | Add to pinlist |
 | MOUNTING KIT 75 TRIMLESS O.F.A. | - | Add to pinlist |
 | PLASTERKIT 101 | - | Add to pinlist |
 | FTL35 F HE DOWN-UP - CURRENT SUPPLY 2 x 0,75 mm² 1,6m | - | Add to pinlist |
 | PLATE 12 N | - | Add to pinlist |
 | MOUNTING KIT R60 TRIMLESS CSC | For cold streched ceiling | Add to pinlist |
 | PIN 18 | - | Add to pinlist |
 | MOUNTING KIT R82 TRIMLESS CSC | For cold streched ceiling | Add to pinlist |
 | MOUNTING KIT SPY 39/52 TRIMLESS CSC | For cold streched ceiling | Add to pinlist |
 | MOUNTING KIT MINIGRID IN 2 CSC | For cold streched ceiling | Add to pinlist |
 | MOUNTING KIT MINIGRID IN 1 CSC | For cold streched ceiling | Add to pinlist |
Pins and plates for bollards
Light altering devices
Acoustic panel
Other
