KIX II PIN 24V 930 PGR
KIX LARGE PIN
Pine Green - 13538 9300 PGR
CRI
Beam angle
CCT
General
| Location | Outdoor |
| Fixation | Floor |
| Installation | Surface mounted |
| IP | IP65 |
| IK | IK03 |
| Weight (kg) | 1.2 |
| Adjustability | 180° swiveling, 360° rotatable |
| Information | INCL.1 x CABLE H05 RN-F 2 x 1mm² 2m
EXCL.LED POWER SUPPLY 24V-DC (non-dimmable or dimmable with PWM output) |
Electrical
| Voltage | 24V-DC |
| Class | III |
| Dimming type | non-dimmable |
| Energy class | E |
| Certificates | CB, ENEC |
Lightsource
| Light source | LED |
| LED information | LED array 5,8W / CRI>90 (R9: 52) / 3000K / 787lm |
| TM-30 Values | Rf: 90 / Rg: 99 |
| SDCM | SDCM1 |
| Riskgroup | RG1 |
| LM80 | L90B10 > 50000 |
| LED technics (light source) | 787lm // 5,8W // 135lm/W |
| LED technics (luminaire) | 602lm // 7W // 90lm/W |
Additional
| Requirements | LED POWER SUPPLY 24V-DC |
| Options | CBOX
IP68 CONNECTION KIT
IP68 CONNECTOR 3P |
| Accessories | KAP KIX
HONEYCOMB KIX |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Finish your specifications
Use the information listed below to complete your product
requirement
LED power supplies
| Product name | Voltage | Class | Dimming type | IP | Cutout shape | Cutout size | max. devices / supply | ||
|---|---|---|---|---|---|---|---|---|---|
 | LED POWER SUPPLY 24V-DC / 24W | 220-240V | II | non-dimmable | IP20 | round | 55 | 3 | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 60W DIM1 | 220-240V | II | 1-10V | IP20 | round | 61 | 8 | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 90W DIM1 | 220-240V | II | 1-10V | IP20 | round | 70 | 12 | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 120W DIM1 | 220-240V | II | 1-10V | IP20 | round | 70 | 17 | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 150W | 100-240V | I | non-dimmable | IP67 | round | 75 | 21 | Add to pinlist |
