OML50 - LED ARRAY DU HO 984mm 930 DIM5
31033 9305
CRI
CCT
General
| Location | Indoor |
| CCT | 3000K |
| IP | IP20 |
| Weight (kg) | 1.1 |
| Information | CLUSTER DOWN: 3863lm/m
CLUSTER UP: 2663lm/m
INCL.DIMMABLE LED POWER SUPPLY
(DALI-2 standard)
CABLING 1 CIRCUIT |
Electrical
| Voltage | 220-240V / 0|50-60Hz |
| Class | I |
| Dimming type | DALI |
| Energy class | D |
| Certificates | EPD, RCM |
Lightsource
| Light source | LED |
| LED information | DOWN: LED cluster 24,5W / CRI>90 (R9: 50) / 3000K / 3802lm
UP: LED cluster 18,1W / CRI>90 (R9: 50) / 3000K / 2621lm |
| TM-30 Values | Rf: 92 / Rg: 100 |
| SDCM | SDCM3 |
| Riskgroup | RG1 |
| LM80 | L80 > 60000 |
| LED technics (light source) | DOWN: 3802lm // 24,5W // 155lm/W
UP: 2621lm // 18,1W // 145lm/W |
| LED technics (luminaire) | DOWN: 3072lm // 28,2W // 109lm/W
UP: 2121lm // 20,8W // 102lm/W |
Additional
| Options | WIRELESS CONTROL DIM5 |
Technical data was measured in optimum conditions.
