SUPERLOOP PLUS HC 120 SBL 930 FBR
FLEMISH BRONZE - 20563 9300 FBR
PANEL 120 LIGHT GREY
20548 0070
CRI
CCT
General
| Location | Interior |
| CCT | 3000K |
| Fixation | Ceiling |
| Installation | Suspended |
| IP | IP20 |
| Weight (kg) | 3.9 |
| Adjustability | non adjustable |
| Information | INCL.PC SBL
EXCL.LED POWER SUPPLY 900-1200mA-DC
INCL.3 x CABLE SUSPENSION SINGLE AUTO. 3.0m
INCL.1 x CABLE 2 x 0.75mm² |
Electrical
| Class | III |
| Dimming type | depending on type of external power supply |
| Energy class | E |
Lightsource
| Light source | LED |
| LED information | LED cluster 36,4-50,3W / CRI>90 (R9: 59) / 3000K / 5022-6665lm |
| SDCM | SDCM3 |
| LED technics (light source) | 6665lm // 50,3W // 132lm/W |
| LED technics (luminaire) | 4005lm // 58W // 69lm/W |
Additional
| Remarks | The indicated efficiency and luminaire lumen are based on the SUPERLOOP without PANEL. Click here for SUPERLOOP PLUS 120 acoustic specifications |
| Requirements | PANEL 120
LED POWER SUPPLY 900 / 1200mA-DC DIM
SUPERLOOP POWERBOX H 900mA
SUPERLOOP POWERBOX H 1200mA |
| Options | CABLE BASE R / S
COVERSET R 62-90-100 / S 62-80-90
CONNECTION ST / CONNECTION TRIMLESS
SUSPENSION ST / SUSPENSION TRIMLESS |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Finish your specifications
Use the information listed below to complete your product
requirement
LED power supplies
| Product name | Voltage | Class | Dimming type | IP | Cutout shape | Cutout size | devices / supply | ||
|---|---|---|---|---|---|---|---|---|---|
 | SUPERLOOP POWERBOX H9 900mA DIM5 B | 220-240V | II | DALI | IP20 | - | - | 1 | Add to pinlist |
 | SUPERLOOP POWERBOX H9 900mA DIM5 W | 220-240V | II | DALI | IP20 | - | - | 1 | Add to pinlist |
| | SUPERLOOP POWERBOX H9 1200mA DIM5 B | 220-240V | II | DALI | IP20 | - | - | 1 | Add to pinlist |
| | SUPERLOOP POWERBOX H9 1200mA DIM5 W | 220-240V | II | DALI | IP20 | - | - | 1 | Add to pinlist |
 | LED POWER SUPPLY 900mA-DC / 60W DIM5 | 220-240V | II | DALI | IP20 | round | 84 | 1 | Add to pinlist |
 | LED POWER SUPPLY 1200mA-DC / 60W DIM5 | 220-240V | I | DALI | IP20 | round | 95 | 1 | Add to pinlist |
 | LED POWER SUPPLY 1200mA-DC / 70W DIM1 | 220-240V | II | 1-10V | IP20 | round | 80 | 1 | Add to pinlist |
| | SUPERLOOP POWERBOX H8 1200mA DIM1 B | 110-240V | I | 1-10V | IP20 | - | - | 1 | Add to pinlist |
| | SUPERLOOP POWERBOX H8 1200mA DIM1 W | 110-240V | I | 1-10V | IP20 | - | - | 1 | Add to pinlist |
