New
SUPERLOOP HC 400 SBL 930 W
WHITE - 20553 9300 W
CRI
CCT
General
| Location | Interior |
| CCT | 3000K |
| Fixation | Ceiling |
| Installation | Suspended |
| IP | IP20 |
| Weight (kg) | 12.9 |
| Adjustability | non adjustable |
| Information | INCL.PC SBL
4 SEGMENTS
EXCL.LED POWER SUPPLY 24-DC
INCL.8 x CABLE SUSPENSION SINGLE AUTO. 3.0m
INCL.4 x CABLE 2 x 0.75mm² |
Electrical
| Voltage | 24V-DC |
| Class | III |
| Energy class | F |
Lightsource
| Light source | LED |
| LED information | 4 x (LED FLEX HP 43,2W / CRI>90 / 3000K / 4200lm) |
| LED technics (light source) | 16800 lm // 172,8 W // 97 lm/W |
| LED technics (luminaire) | 7560lm // 199W // 38lm/W |
Additional
| Requirements | LED POWER SUPPLY 24V-DC |
| Options | CABLE BASE R / S
COVERSET R 62-90-100 / S 62-80-90
CONNECTION ST / CONNECTION TRIMLESS
SUSPENSION ST / SUSPENSION TRIMLESS |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Finish your specifications
Use the information listed below to complete your product
requirement
LED power supplies
| Product name | Voltage | Class | Dimming type | IP | Cutout shape | Cutout size | devices / supply | ||
|---|---|---|---|---|---|---|---|---|---|
 | LED POWER SUPPLY 24V-DC / 90W IP67 DIM1 | 110-240V | II | 1-10V | IP67 | round | 75 | 1/4 | Add to pinlist |
| | LED POWER SUPPLY 24V-DC / 120W IP67 DIM1 | 110-240V | II | 1-10V | IP67 | round | 75 | 1/4 | Add to pinlist |
| | LED POWER SUPPLY 24V-DC / 90W IP67 DIM5 | 110-240V | II | DALI | IP67 | round | 75 | 1/4 | Add to pinlist |
| | LED POWER SUPPLY 24V-DC / 120W IP67 DIM5 | 110-240V | II | DALI | IP67 | round | 75 | 1/4 | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 90W DIM1 | 220-240V | II | 1-10V | IP20 | round | 70 | 1/4 | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 120W DIM1 | 220-240V | II | 1-10V | IP20 | round | 70 | 1/4 | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 100W DIM5 | 220-240V | II | DALI | IP20 | round | 70 | 1/4 | Add to pinlist |
 | LED POWER SUPPLY 24V-DC / 150W | 100-240V | I | non-dimmable | IP67 | round | 75 | 2/4 | Add to pinlist |
