SPY 90 ON 92718 DIM1 W

SPY 90 ON 93018 DIM1 W

White - 19882 9311 W

SPY 90 TUBE B

Black - 19810 0170 B
More info
CRI
Beam angle
CCT

General

Location
Indoor
CCT
3000K
Fixation
Ceiling
Installation
Surface mounted
IP
IP20
Weight (kg)
1.1
Adjustability
0° to 90° swiveling, 355° rotatable
Information
REFLECTOR SP-18° INCL.DIMMABLE LED POWER SUPPLY 700mA-DC Optional REFLECTORS 30° & 45° available

Electrical

Voltage
120-240V / 50-60Hz
Class
II
Dimming type
1-10V
Energy class
C
Certificates
CB, ENEC

Lightsource

Light source
LED
LED information
LED array 23,2W / CRI>90 (R9: 52) / 3000K / 3169lm
TM-30 Values
Rf: 90 / Rg: 99
SDCM
SDCM1
Riskgroup
RG1
LM80
L90B10 > 50000
LED technics (light source)
3169lm // 23,2W // 136lm/W
LED technics (luminaire)
2287lm // 27W // 86lm/W

Additional

Requirements
SPY 90 TUBE
Accessories
HONEYCOMB 75 SPREAD LENS 75 LINEAR SPREAD LENS 75 SOFTENING LENS 75 GLASS SBL 75
Technical data was measured in optimum conditions.
