HEDRA ON 2 93033 DIM1 B-B
Black-Black - 473 231 812 932 ED1 B-B
VIZIR TUBE B
Black - 473 01 00 B
CRI
Beam angle
CCT
General
| Location | Indoor |
| CCT | 3000K |
| Fixation | Ceiling, Wall |
| Installation | Surface mounted |
| IP | IP20 |
| Weight (kg) | 0.9 |
| Adjustability | 0° to 90° swiveling, 355° rotatable |
| Information | 2 x REFLECTOR FL-33°
INCL.DIMMABLE LED POWER SUPPLY 350mA-DC |
Electrical
| Voltage | 220-240V / 50-60Hz |
| Class | I |
| Dimming type | 1-10V |
| Energy class | C |
| Certificates | EAC, ENEC, RCM |
Lightsource
| Light source | LED |
| LED information | 2 x (LED array 5,8W / CRI>90 (R9: 52) / 3000K / 787lm) |
| TM-30 Values | Rf: 90 / Rg: 99 |
| SDCM | SDCM1 |
| Riskgroup | RG1 |
| LM80 | L90B10 > 50000 |
| LED technics (light source) | 1574lm // 11,6W // 135lm/W |
| LED technics (luminaire) | 790lm // 13W // 59lm/W |
Additional
| Requirements | VIZIR TUBE |
| Accessories | VIZIR HONEYCOMB
VIZIR SOFTENING LENS |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Finish your specifications
Use the information listed below to complete your product
optional
Control gear, ballast and transformers
| Product name | Voltage | Class | Dimming type | ||
|---|---|---|---|---|---|
 | WIRELESS CONTROL 5A DIM1 | 100-240V | II | WDL = wireless dimmable | Add to pinlist |
