New

SPLITLINE / SHIFTLINE modules

Discover the Complete Range of Magnetic Profiles and Modules with this Guide.

With the low-voltage magnetic systems, Delta Light takes it to the next level in the profile section. These profiles offer the highest degree of freedom and flexibility, as all modules have a magnetic fixation. For recessed applications, Splitline M20 and M52 allow for a neat, trimless installation, while the new Splitline M20 ST offers a small trim to conceal the cut edge, allowing installation into a number of materials beyond drywall. Shiftline M26H + SBL, M26H, & M26L can be used for projects where surface or suspended mounting is required. To create the optimal light setting, multiple light modules are available: spot modules with different beams and lumen packages going up to 2000lm for accent lighting, linear LED lines for general or wallwash lighting and pendant modules for an elegant finish of the room.

All modules can be placed toolfree into the profile and repositioned afterwards thanks to their magnetic fixation. Simply click the module into the profile and both mechanical and electrical connection are ensured. As this family of profiles is powered by 48V, Smart 48 can be used for an easy 2-wire dimming/power solution. Add the Modulator for 0-10V control. For individual control of luminaires, one can opt for a DALI controlled system.

Lumens: 166 lm - 2287 lm
Wattages: 2 W - 29 W
Beam range: 8-43° / 8° / 12-45° / 13° / 14° / 18° / 20° / 21° / 24° / 25° / 26-46° / 28/41° / 30° / 32° / 33° / 35° / 36° / 37° / 40° / 45° / 49° / 67°
CCT range: Warm White (+3000K) / Halogen White (+2700K) / Warm White (+3500K) / Soft Dim (3000K - 1800k) / Tunable White (2700K - 6500k)

1Product

SPLITLINE M20/SHIFTLINE M26H - SPY 66

Add to list
M20/M26H - SPY 66 92718 MDL B
Magnetic modules to be used with the SPLITLINE M and SHIFTLINE M profiles.
Lumens: 746 lm - 2079 lm
Wattages: 10 W - 29 W
Beam range: 18° / 30° / 45°
CCT range: Halogen White (+2700K) / Warm White (+3000K) / Warm White (+3500K) / Tunable White (2700K - 6500k)
Spec sheet
