New
ENTERO RD-M TW 96545 B
Black - 28412 9030 B
CRI
Beam angle
CCT
General
| Location | Indoor |
| CCT | 2700K-6500K |
| Fixation | Ceiling |
| Installation | Recessed |
| Cutout shape | round |
| Cutout size (mm) | 92 |
| Min. recessed depth (mm) | 130 |
| Thickness of mounting surface (mm) | max.16 |
| IP | IP20 |
| Weight (kg) | 0.4 |
| Adjustability | 0° to 30° swiveling, 355° rotatable |
| Information | REFLECTOR WFL-45°
EXCL.LED POWER SUPPLY 500mA-DC TW - (DALI DT8)
Optional REFLECTORS 18° & 30° available |
Electrical
| Class | III |
| Dimming type | depending on power supply |
| Energy class | E |
| Certificates | CB, ENEC, EPD |
Lightsource
| Light source | LED |
| LED information | LED array 9W / CRI>90 (R9: 50) / 2700K-6500K / 1087lm |
| TM-30 Values | Rf: 89 / Rg: 100 |
| SDCM | SDCM2 |
| Riskgroup | RG1 |
| LM80 | L90B10 > 50000 |
| LED technics (light source) | 1087lm // 9W // 121lm/W |
| LED technics (luminaire) | 792lm // 10W // 77lm/W |
Additional
| Requirements | LED POWER SUPPLY 500mA-DC TW |
| Options | ENTERO RD-M MOUNTING SET S2 |
| Accessories | ENTERO M HONEYCOMB
ENTERO M LINEAR SPREAD LENS
ENTERO M SPREAD LENS
ENTERO M SOFTENING LENS
ENTERO M GLASS SBL |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Ceiling compatibility
Please find an overview of the suitable ceiling types for this specific product.
Ceiling Type
Mounting kit
-
-
-
-
-
Finish your specifications
Use the information listed below to complete your product
requirement
LED power supplies
| Product name | Voltage | Class | Dimming type | IP | Cutout shape | Cutout size | devices / supply | ||
|---|---|---|---|---|---|---|---|---|---|
 | LED POWER SUPPLY 500mA-DC 2CH TW DIM5 | 220-240V | II | DALI | IP20 | round | 85 | 1->2 | Add to pinlist |
